PE Braided + SS 316L Helical Wire Reinforced Silicone Hose

Description

Dual reinforced hose with Polyester braid and SS wire built for pressure and vacuum lines where structural stability is key.

This Platinum Cured Silicone Hose is built for applications that demand both high pressure resistance and vacuum capability while maintaining excellent structural stability. The polyester braid provides exceptional burst strength, and the SS 316L helical wire prevents kinking and collapse under suction. Together, they create a rugged, long-lasting solution for dynamic and static installations.

Key Features

Dual Reinforcement – Polyester braid for burst resistance + SS 316L wire for vacuum stability.
Platinum-Cured Silicone – Ultra-pure, inert, odorless, and compliant with FDA & USP Class VI.
High Vacuum Capability – Up to 780 mm Hg (size dependent).
Excellent Temperature Range – –60°C to +200°C.
Corrosion-Resistant Construction – 316L stainless steel wire withstands aggressive environments.
Kink & Collapse Resistant – Maintains shape even under bending and vacuum load.

Applications

Pharmaceutical and biotech transfer lines
High-pressure and high-vacuum process applications
Food and beverage suction and discharge
Chemical handling where flexibility and durability are essential

Technical Specifications

PLATINUM CURED SILICONE HOSE REINFORCED WITH POLYESTER BRAIDING AND SS 316L HELICAL WIRE
SIZE in MM	SIZE in Inch	Max. Working Pressure (Bar)	Min. Burst Pressure (Bar)	Min. Bend Radius (MM)	Vacuum Value in MM HG
6×13	1/4″	13.5	49.5	45	780
9×16	11/32″	13.5	49.5	55	780
12×20	1/2″	12	46.5	65	780
16×24	5/8″	11.5	36.5	75	780
19×27	3/4″	10.5	31.5	85	780
25×35	1″	10	31.5	120	780
32×42	1 1/4″	9	28.5	135	520
37×47	1 1/2″	8.5	26.5	165	520
50×62	2″	7	23.5	235	410
64×76	2 1/2″	5	21	380	390
